19-0969; Rev 0; 9/07
MAX7359 Evaluation Kit
General Description
The MAX7359 evaluation kit (EV kit) is an assembled
and tested printed-circuit board (PCB) that demon-
strates the MAX7359 2-wire interfaced low-EMI key
switch controller. Windows ? 2000/XP/Vista-compatible
software provides a handy user interface to exercise
the features of the MAX7359.
Features
? Windows 2000/XP/Vista (32-Bit)-Compatible
Software
? Proven PCB Layout
? Complete Evaluation System
? 8 x 8 Key Matrix Included
? Optional PORT2–PORT7 Output LEDs
? Fully Assembled and Tested
Ordering Information
PART
MAX7359EVKIT+
TYPE
EV kit
+Denotes lead-free and RoHS-compliant.
Component List
DESIGNATION
QTY
DESCRIPTION
DESIGNATION
QTY
DESCRIPTION
0.1μF ±10%, 10V (min) X7R
22pF ±5%, 50V C0G ceramic
C1, C5–C9,
C17, C18, C37
9
ceramic capacitors (0603)
TDK C1608X7R1C104K
Taiyo Yuden EMK107BJ104KA
C30, C31
2
capacitors (0603)
Murata GRM1885C1H220J
TDK C1608C0G1H220J
Murata GRM188R71C104K
Taiyo Yuden UMK107CG220KZ
C2
C4
0
1
Not installed, capacitor (0603)
0.033μF ±10%, 6.3V (min) X7R
ceramic capacitor (0603)
TDK C1608X7R1E333K
Murata GRM188R71E333K
Taiyo Yuden EMK107BJ333KA
H1–H4
J1
J3 (JTAG)
4
1
1
6-pin headers
USB series type-B right-angle PC-
mount receptacle
Vertical header, 2 x 5 pins
(keyed pin 7)
JU1
1
Dual-row vertical header, 2 x 4 pins
C10, C39
2
1μF ±10%, 16V X5R ceramic
capacitors (0603)
TDK C1608X5R1C105K
Murata GRM188R61C105K
AVX 0603YD105MAT
JU2
JU3–JU8
JU9–JU13
1
6
0
3-pin header
2-pin headers
Not installed, 2-pin headers—PCB
shorted trace
KEMET C0603C105K4PAC
Momentary 6mm pushbutton
10μF ±20%, 16V X5R ceramic
capacitors (1206)
KEY0–KEY63
64
switches
OMRON B3F1000
C11, C12, C38,
C40
4
Murata GRM31CR61C106M
TDK C3216X5R1C106M
Ferrite bead (0603)
Panasonic ECJ3YB1C106M
KEMET C1206C106M4PAC
10pF ±5%, 50V C0G ceramic
capacitors (0603)
L1
LED1–LED8
R1, R2
1
8
2
TDK MMZ1608R301A
Murata BLM18SG700 TN1
Red LEDs (T1-3/4)
27 Ω ±5% resistors (0603)
C15, C16
2
Murata GRM1885C1H100J
TDK C1608C0G1H100J
Taiyo Yuden UMK107CG100DZ
R3, R7, R8
R4
R5
3
1
1
1.5k Ω ±5% resistors (0603)
470 Ω ±5% resistor (0603)
2.2k Ω ±5% resistor (0603)
Windows is a registered trademark of Microsoft Corp.
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
1
